Orbea Rise M10 20mph
$8,599.00
Details
Rise returns, lighter than ever, with more battery options and the cleanest integration, ready to open up longer adventures and take you to even more epic locations.
| Small | Medium | Large | X-Large | |
|---|---|---|---|---|
| 11 - HEAD TUBE LENGTH | 381 | 419 | 457 | 508 |
| 22 - CHAINSTAY LENGTH (ACTUAL) | 565 | 592 | 619 | 649 |
| 33 - BB DROP | 95 | 105 | 120 | 140 |
| 44 - WHEEL BASE | 445 | 445 | 445 | 445 |
| 55 - SEAT ANGLE (VIRTUAL) | 336 | 336 | 336336 | 336 |
| 66 - STANDOVER HEIGHT* | 35/32 | 35/32 | 35/32 | 35/32 |
| 77 - BB - FRONT WHEEL AXLE | 1180 | 1205 | 1229 | 1255 |
| 88 - TRAIL | 66º/65,5º | 66º/65,5º | 66º/65,5º | 66º/65,5º |
| 99 - WIDTH | 77º/76,5º | 77º/76,5º | 77º/76,5º | 77º/76,5º |
| 1010 - STACK HIGH POSITION | 710 | 736 | 766 | 776 |
| 1110 - STACK LOW POSITION | 425 | 450 | 474 | 500 |
| 1211 - REACH | 604 | 613 | 627 | 646 |
| 1312 - STACK MAX | 547 | 547 | 547 | 547 |
| Frame Size | Rider height (in) |
|---|---|
| Small | 59.1"-65.0" |
| Medium | 63.0"-68.9" |
| Large | 66.9"-72.8" |
| X-Large | 70.9"-78.0" |
Due to supply-chain issues, Specs are subject to change without notice.
Specs
| Frame | Orbea Rise Evo OMR 2023, 140mm travel, 29" wheels, Concentric Boost 12x148 |
|---|---|
| Fork | Fox 36 Float Factory 150 Grip2 QR15x110 Kashima |
| Rear Shock | Fox FLOAT X Factory 2-Position Evol LV Kashima custom tune 210x55mm |
| Wheels | OQUO Mountain Control MC32TEAM |
| Tires | Maxxis Dissector 2.40" 120 TPI 3CMaxxTerra Exo+ TLR |
| Crankset | Shimano Steps EM600 |
| Chainrings | e*thirteen e*spec Direct Mount 32T Boost |
| Shifters | Shimano XT M8100 I-Spec EV |
| Rear Derailleur | Shimano XT M8100 SGS Shadow Plus |
| Cassette/Freewheel | Shimano CS-M7100 10-51t 12-Speed |
| Chain | Shimano M7100 |
| Brakes | Shimano M6120 Hydraulic Disc |
| Handlebars | OC Mountain Control MC10 Carbon, Rise 20, Width 800 |
| Stem | OC Mountain Control MC20, 0º |
| Headset | Alloy 1-1/2", Black Oxidated Bearing |
| Seatpost | OC Mountain Control MC20, 31.6mm, Dropper |
| Saddle | Fizik Taiga S-alloy rail |
| Pedals | Sold separately |
| Motor | Shimano EP801-RS |
| Battery | Orbea Internal 360Wh (Optional 540Wh) |
| Controller/Display | EN600-L |
| Charger | Orbea 2.Generation eBike Smart charger 42V/2-4A |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN |
|---|---|---|
| Carbon Raw/Shark Grey (Matt) / Small | 08434446326080 | N67503V2 |
| Carbon Raw/Shark Grey (Matt) / Medium | 08434446326110 | N67505V2 |
| Carbon Raw/Shark Grey (Matt) / Large | 08434446326141 | N67507V2 |
| Carbon Raw/Shark Grey (Matt) / X-Large | 08434446326172 | N67509V2 |
| Chameleon Goblin Green (Gloss)/Black (Matt) / Small | 08434446326073 | N67503V1 |
| Chameleon Goblin Green (Gloss)/Black (Matt) / Medium | 08434446326103 | N67505V1 |
| Chameleon Goblin Green (Gloss)/Black (Matt) / Large | 08434446326134 | N67507V1 |
| Chameleon Goblin Green (Gloss)/Black (Matt) / X-Large | 08434446326165 | N67509V1 |
